Sedimentation Water Treatment Equipment with Micro Sand Loading for Effluent Multi Effect Clarification and Enhanced Flocculation

Name: Sedimentation Water Treatment Equipment with Micro Sand Loading for Effluent Multi Effect Clarification and Enhanced Flocculation
Brand: Everest Technology (Wuxi) Co., Ltd
SKU: WPG-40
Availability: InStock

Brand Name:	EVEREST
Model Number:	WPG-40
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	800 units/year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

lS09001,IS014001, ISO45001, (TS ) Grade A, PED2014/68/EU,AP1 5LC, API 5LD, ASME, CCS, LR, DNV , BVRINA and ABS.

Product:

Sedimentation Water Treatment Equipment With Micro Sand Loading For Effluent Multi Effect Clarification And Enhanced Flocculation

Model:

WPG-40

Capacity:

40m³/h

Dissohedair Quantity:

9m³/h

Reflow Pump:

Exhaust:

0.75

Scavenger:

0.2

Mixer:

0.75

Length(m):

Width:

2.2m

Height:

2.1m

Nozzle List:

Iniet:200,Outlet:200,Sludge Outlet:100,Empty Mouth:80

Application Field:

Removal Of Various Heavy Metal Ions In Electroplating Wastewater,Removal Of Impurities From Tanning Wastewater,ect

Technical Advantages:

The Utilization Efficiency Of Dissolved Air Water Is High, And The Air Flotation Equipment Works Stably, Low Space Requirements, Low Energy Consumption, And Easy Transportation ,ect

Surface Load Of The Precipitation Section:

40- 65m³/(m²·h)

SS And TP Removal Rate:

Over 9 0 %

COD Removal Rate:

40%

Project Case:

Landfill Leachate Pretreatment ,ect

Packaging Details:

according to customers' demand

Supply Ability:

800 units/year

Highlight:

clarification water treatment equipment

clarification air flotation water treatment

flocculation water treatment equipment

Product Description

Sedimentation Water Treatment Equipment with Micro Sand Loading for Effluent Multi Effect Clarification and Enhanced Flocculation

The Integrated Microsand Sedimentation & DAF System combines advanced microsand-enhanced clarification with optimized dissolved air flotation (DAF) technology, delivering unmatched efficiency in industrial and municipal wastewater treatment. Designed for industries prioritizing space savings, energy reduction, and operational simplicity, this system achieves superior contaminant removal while slashing costs and complexity.

Core Advantages

✅ Space-Saving Integration:

Modular, compact design reduces footprint by 40-60% vs. traditional clarifier-DAF setups.
Pre-assembled skid-mounted units enable plug-and-play installation, minimizing civil works.

✅ Energy & Cost Efficiency:

Low-energy compressors cut power consumption by 30%, with noise levels below 65 dB(A).
Microsand recycling enhances flocculation, reducing chemical usage by 15-25%.

✅ Smart Automation:

Auto-adjusted dissolved air pressure (2-6 bar) and reflux ratio (10-30%) ensure stable performance under fluctuating loads.
Remote IoT monitoring via HMI/SCADA for real-time TSS, turbidity, and flow tracking.

✅ Flexible Configuration:

Single/Dual Dissolved Air Units: Choose based on influent quality (COD 200-10,000 mg/L).
High-Efficiency Release Valves: Achieve >90% microbubble utilization (20-50μm) for rapid oil/solid separation.
Global Compatibility: Standardized components support local OEM parts procurement, slashing lead times.

Modelspecifications andrelated technical parameters

Model	Capacity m³/h	Dissohedair quantity	Power Kw				Dimension(m)			Nozzle list
Model	Capacity m³/h	Dissohedair quantity	Reflowpump	Exhaust	Scavenger	Mixer	length	width	height	Iniet(A)	Outlet(B)	Sludge outlet(C)	Empty mouth(D)
WPG-1	~1	~0.7	0.55	0.55	0.2	0.4	1.7	0.55	1.1	32	32	40	32
WPG-2	~2	~1	0.55	0.55	0.2	0.4	2.8	0.65	4.5	40	40	50	40
WPG-3	~3	~2	0.75	0.55	0.2	0.4	3.5	0.8	1.6	80	80	80	50
WPG-5	~5	~3	1.1	0.55	0.2	0.75	4	1	1.7	80	80	80	50
WPG-10	~10	~4	1.5	0.75	0.2	0.75	5	1.2	2	100	100	100	80
WPG-15	~15	~5	2.2	0.75	0.2	0.75	5.5	1.5	2	125	125	100	80
WPG-20	~20	~7	3	0.75	0.2	0.75	5.8	1.8	2	150	150	100	80
WPG-30	~30	~8	3	0.75	0.2	0.75	6	2	2.1	150	150	100	80
WPG-40	~40	~9	4	0.75	0.2	0.75	7	2.2	2.1	200	200	100	80
WPG-50	~50	~10	5.5	0.75	0.2	0.75	7.2	2.5	3	200	200	100	80
WPG-60	~60	~10	5.5	0.75	0.2	0.75	7.4	2.5	3	200	200	100	80
WPG-70	~70	~12	5.5	0.75	0.2	1.1	7.6	2.5	3	200	200	100	80
WPG-80	~80	~12	5.5	0.75	0.2	1.1	7.8	2.5	3	200	200	100	80
WPG-100	~100	~15	5.5	0.75	0.2	1.1	8	2.5	3	200	250	100	100
WPG-120	~120	~15	5.5	0.75	0.4	2.2	8.5	2.5	3	250	250	200	100
WPG-150	~150	~30	7.5	1.5	0.4	2.2	9	3.1	3	250	250	200	100
WPG-200	~200	~30	7.5	1.5	0.4	2.2	10	3.1	3	250	350	250	100
WPG-300	~300	~42	15	2.2	0.75	2.2	14	3.6	3	300	400	250	100
WPG-400	~400	~42	15	2.2	0.75	2.2	14	3.8	3	400	500	250	100

Application field

Treatment of theindustrial wastewaterin

chemical,food,woolspinning,slaugh-tering,

brewing,oredressing and washingindustries

Domestic sewage pretreatment and sludge thickening

Papermaking white water pulp recyclingand water reuse

Advanced treatment of fluorine-containing wastewater such as coal mines, photovoltaics, batteries, etc

Removal of various heavy metal ions in electroplating wastewater

Removal of impurities from tanning wastewater

Separation of oil refining wastewater and oil pollution

Project Case

Landfill leachate pretreatment

Project Overview: Guangdong Nansha Landfill Leachate Treatment and Disposal Project, this equipment procurement is a supporting construction of landfill leachate wastewater treatment project pretreatment system biogas slurry wastewater treatment scale pretreatment, removal of SS and oil in the water, treatment water: 400m3/d Project Address: Guangdong

Certificate

API-5LD AUTHENTICATION	American Petroleum Institute API 5LC Certificate	ASME Certificate in the United States	EU PED&AD2000 certificate	ABS classification society certification certificate in the United States	DNV Det Norske Veritas Certificate	RINA Italian Bureau of Shipping Certificate	BV French Bureau of Shipping certification	LR Lloyd's Register Certificate of Approval	Customs Union EAC Certificate	Russian GOST certificate

Packing and Shipping:

This peoduct is carefully packaged to ensure its safe delivery to you. It is wrapped in protective packaging material to prevent any scratches or damage during transit.

For shipping, we use trusted delivery services to make sure your product arrives promptly and in excellent condition. You can track your order to know exactly when it will reach you.

Upgrade to Smarter Water Treatment – Maximize Efficiency, Minimize Footprint & Costs!
