Sedimentation Water Treatment Equipment with Micro Sand Loading for Enhanced Flocculation and Multi Effect Clarification

Name: Sedimentation Water Treatment Equipment with Micro Sand Loading for Enhanced Flocculation and Multi Effect Clarification
Brand: Everest Technology (Wuxi) Co., Ltd
SKU: WPG-30
Availability: InStock

Brand Name:	EVEREST
Model Number:	WPG-30
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	800 units/year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

lS09001,IS014001, ISO45001, (TS ) Grade A, PED2014/68/EU,AP1 5LC, API 5LD, ASME, CCS, LR, DNV , BVRINA and ABS.

Product:

Sedimentation Water Treatment Equipment With Micro Sand Loading For Enhanced Flocculation And Multi Effect Clarification

Model:

WPG-30

Capacity:

30m³/h

Dissohedair Quantity:

8m³/h

Reflow Pump:

Exhaust:

0.75

Scavenger:

0.2

Mixer:

0.75

Length(m):

Width:

Height:

2.1m

Nozzle List:

Iniet:150,Outlet:150,Sludge Outlet:100,Empty Mouth:80

Application Field:

Removal Of Various Heavy Metal Ions In Electroplating Wastewater,Removal Of Impurities From Tanning Wastewater,ect

Technical Advantages:

The Utilization Efficiency Of Dissolved Air Water Is High, And The Air Flotation Equipment Works Stably, Low-noise ,ect

Surface Load Of The Precipitation Section:

40- 65m³/(m²·h)

SS And TP Removal Rate:

Over 9 0 %

COD Removal Rate:

40%

Project Case:

ABS Wastewater Treatment In The Chemical Industry ,ect

Packaging Details:

according to customers' demand

Supply Ability:

800 units/year

Highlight:

flocculation water treatment equipment

flocculation air flotation water treatment

clarification water treatment equipment

Product Description

Sedimentation Water Treatment Equipment with Micro Sand Loading for Enhanced Flocculation and Multi Effect Clarification

Application field:

Algae removal and turbidity reductionforlake water,riverwater used astapwaterand for landscape use.
Removal of heavy metal ions fromelectroplating wastewater.
Domestic sewage pretreatmentand sludge thickening.
Separation of refinery,wastewater and oil dirt.
Papermaking white water pulprecovery and clean water reuse.
Fluorine containing wastewater from coalmines,photovoltaics,batteries,and other industries Deep processing.

Modelspecifications andrelated technical parameters

Model	Capacity m³/h	Dissohedair quantity	Power Kw				Dimension(m)			Nozzle list
Model	Capacity m³/h	Dissohedair quantity	Reflowpump	Exhaust	Scavenger	Mixer	length	width	height	Iniet(A)	Outlet(B)	Sludge outlet(C)	Empty mouth(D)
WPG-1	~1	~0.7	0.55	0.55	0.2	0.4	1.7	0.55	1.1	32	32	40	32
WPG-2	~2	~1	0.55	0.55	0.2	0.4	2.8	0.65	4.5	40	40	50	40
WPG-3	~3	~2	0.75	0.55	0.2	0.4	3.5	0.8	1.6	80	80	80	50
WPG-5	~5	~3	1.1	0.55	0.2	0.75	4	1	1.7	80	80	80	50
WPG-10	~10	~4	1.5	0.75	0.2	0.75	5	1.2	2	100	100	100	80
WPG-15	~15	~5	2.2	0.75	0.2	0.75	5.5	1.5	2	125	125	100	80
WPG-20	~20	~7	3	0.75	0.2	0.75	5.8	1.8	2	150	150	100	80
WPG-30	~30	~8	3	0.75	0.2	0.75	6	2	2.1	150	150	100	80
WPG-40	~40	~9	4	0.75	0.2	0.75	7	2.2	2.1	200	200	100	80
WPG-50	~50	~10	5.5	0.75	0.2	0.75	7.2	2.5	3	200	200	100	80
WPG-60	~60	~10	5.5	0.75	0.2	0.75	7.4	2.5	3	200	200	100	80
WPG-70	~70	~12	5.5	0.75	0.2	1.1	7.6	2.5	3	200	200	100	80
WPG-80	~80	~12	5.5	0.75	0.2	1.1	7.8	2.5	3	200	200	100	80
WPG-100	~100	~15	5.5	0.75	0.2	1.1	8	2.5	3	200	250	100	100
WPG-120	~120	~15	5.5	0.75	0.4	2.2	8.5	2.5	3	250	250	200	100
WPG-150	~150	~30	7.5	1.5	0.4	2.2	9	3.1	3	250	250	200	100
WPG-200	~200	~30	7.5	1.5	0.4	2.2	10	3.1	3	250	350	250	100
WPG-300	~300	~42	15	2.2	0.75	2.2	14	3.6	3	300	400	250	100
WPG-400	~400	~42	15	2.2	0.75	2.2	14	3.8	3	400	500	250	100

Application field

Treatment of theindustrial wastewaterin

chemical,food,woolspinning,slaugh-tering,

brewing,oredressing and washingindustries

Domestic sewage pretreatment and sludge thickening

Papermaking white water pulp recyclingand water reuse

Advanced treatment of fluorine-containing wastewater such as coal mines, photovoltaics, batteries, etc

Removal of various heavy metal ions in electroplating wastewater

Removal of impurities from tanning wastewater

Separation of oil refining wastewater and oil pollution

Project Case

ABS wastewater treatment in the chemical industry

Project Overview:Mainly remove a large amount of SS in ABS wastewater

Quantity of treated water:10800T/D

Project address:Panjin City,Liaoning

Certificate

API-5LD AUTHENTICATION	American Petroleum Institute API 5LC Certificate	ASME Certificate in the United States	EU PED&AD2000 certificate	ABS classification society certification certificate in the United States	DNV Det Norske Veritas Certificate	RINA Italian Bureau of Shipping Certificate	BV French Bureau of Shipping certification	LR Lloyd's Register Certificate of Approval	Customs Union EAC Certificate	Russian GOST certificate

Packing and Shipping:

This peoduct is carefully packaged to ensure its safe delivery to you. It is wrapped in protective packaging material to prevent any scratches or damage during transit.

For shipping, we use trusted delivery services to make sure your product arrives promptly and in excellent condition. You can track your order to know exactly when it will reach you.

Global Support
Free process design + on-site commissioning . Contact now for instant quote & technical dossier!
