Improved Water Treatment Efficiency with Micro Sand Loading and Enhanced Flocculation in Multi Effect Clarification Equipment

Name: Improved Water Treatment Efficiency with Micro Sand Loading and Enhanced Flocculation in Multi Effect Clarification Equipment
Brand: Everest Technology (Wuxi) Co., Ltd
SKU: WPG-3
Availability: InStock

Brand Name:	EVEREST
Model Number:	WPG-3
MOQ:	Negotiable
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T
Supply Ability:	800 units/year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

lS09001,IS014001, ISO45001, (TS ) Grade A, PED2014/68/EU,AP1 5LC, API 5LD, ASME, CCS, LR, DNV , BVRINA and ABS.

Product:

Improved Water Treatment Efficiency With Micro Sand Loading And Enhanced Flocculation In Multi Effect Clarification Equipment

Model:

WPG-3

Capacity:

3m³/h

Dissohedair Quantity:

2m³/h

Reflow Pump:

0.75

Exhaust:

0.55

Scavenger:

0.2

Mixer:

0.4

Dimension(m):

3.5l/0.8w/1.6h

Nozzle List:

Iniet:80,Outlet:80,Sludge Outlet:80,Empty Mouth:50

Application Field:

Removal Of Various Heavy Metal Ions In Electroplating Wastewater,Removal Of Impurities From Tanning Wastewater,ect

Technical Advantages:

Single Dissolved Air Device Or Double Dissolved Air Device Can Be Provided According To Water Quality And Process Requirements.High-efficiency Releaser Is Used To Improve The Utilization Efficiency Of Thedissolved-air Water,and Guarantee The Working Stabil

Surface Load Of The Precipitation Section:

40- 65m³/(m²·h)

SS And TP Removal Rate:

Over 9 0 %

COD Removal Rate:

40%

Packaging Details:

according to customers' demand

Supply Ability:

800 units/year

Highlight:

flocculation clarification equipment

flocculation water recycling equipment

clarification water recycling equipment

Product Description

Improved Water Treatment Efficiency with Micro Sand Loading and Enhanced Flocculation in Multi Effect Clarification Equipment

Product Description
The WPG Combined Dissolved Air Flotation (DAF) and Microsand-Loaded Multi-Effect Clarification System integrate cutting-edge technologies to deliver unparalleled wastewater treatment performance, addressing challenges in industrial effluents, municipal sewage, and water plant pretreatment. Designed for efficiency, compactness, and compliance, these systems optimize contaminant removal while minimizing operational costs and footprint.


Modelspecifications andrelated technical parameters

Model	Capacity m³/h	Dissohedair quantity	Power Kw				Dimension(m)			Nozzle list
Model	Capacity m³/h	Dissohedair quantity	Reflowpump	Exhaust	Scavenger	Mixer	length	width	height	Iniet(A)	Outlet(B)	Sludge outlet(C)	Empty mouth(D)
WPG-1	~1	~0.7	0.55	0.55	0.2	0.4	1.7	0.55	1.1	32	32	40	32
WPG-2	~2	~1	0.55	0.55	0.2	0.4	2.8	0.65	4.5	40	40	50	40
WPG-3	~3	~2	0.75	0.55	0.2	0.4	3.5	0.8	1.6	80	80	80	50
WPG-5	~5	~3	1.1	0.55	0.2	0.75	4	1	1.7	80	80	80	50
WPG-10	~10	~4	1.5	0.75	0.2	0.75	5	1.2	2	100	100	100	80
WPG-15	~15	~5	2.2	0.75	0.2	0.75	5.5	1.5	2	125	125	100	80
WPG-20	~20	~7	3	0.75	0.2	0.75	5.8	1.8	2	150	150	100	80
WPG-30	~30	~8	3	0.75	0.2	0.75	6	2	2.1	150	150	100	80
WPG-40	~40	~9	4	0.75	0.2	0.75	7	2.2	2.1	200	200	100	80
WPG-50	~50	~10	5.5	0.75	0.2	0.75	7.2	2.5	3	200	200	100	80
WPG-60	~60	~10	5.5	0.75	0.2	0.75	7.4	2.5	3	200	200	100	80
WPG-70	~70	~12	5.5	0.75	0.2	1.1	7.6	2.5	3	200	200	100	80
WPG-80	~80	~12	5.5	0.75	0.2	1.1	7.8	2.5	3	200	200	100	80
WPG-100	~100	~15	5.5	0.75	0.2	1.1	8	2.5	3	200	250	100	100
WPG-120	~120	~15	5.5	0.75	0.4	2.2	8.5	2.5	3	250	250	200	100
WPG-150	~150	~30	7.5	1.5	0.4	2.2	9	3.1	3	250	250	200	100
WPG-200	~200	~30	7.5	1.5	0.4	2.2	10	3.1	3	250	350	250	100
WPG-300	~300	~42	15	2.2	0.75	2.2	14	3.6	3	300	400	250	100
WPG-400	~400	~42	15	2.2	0.75	2.2	14	3.8	3	400	500	250	100


Application field

Treatment of theindustrial wastewaterin

chemical,food,woolspinning,slaugh-tering,

brewing,oredressing and washingindustries

Domestic sewage pretreatment and sludge thickening

Papermaking white water pulp recyclingand water reuse

Advanced treatment of fluorine-containing wastewater such as coal mines, photovoltaics, batteries, etc

Removal of various heavy metal ions in electroplating wastewater

Removal of impurities from tanning wastewater

Separation of oil refining wastewater and oil pollution

Certificate

API-5LD AUTHENTICATION	American Petroleum Institute API 5LC Certificate	ASME Certificate in the United States	EU PED&AD2000 certificate	ABS classification society certification certificate in the United States	DNV Det Norske Veritas Certificate	RINA Italian Bureau of Shipping Certificate	BV French Bureau of Shipping certification	LR Lloyd's Register Certificate of Approval	Customs Union EAC Certificate	Russian GOST certificate

Packing and Shipping:

This peoduct is carefully packaged to ensure its safe delivery to you. It is wrapped in protective packaging material to prevent any scratches or damage during transit.

For shipping, we use trusted delivery services to make sure your product arrives promptly and in excellent condition. You can track your order to know exactly when it will reach you.

Upgrade Your Wastewater Treatment Today – Achieve Cleaner Water, Lower Costs, and Sustainable Operations!
